VVDI RKE BOX Remote Control Switching Box support 3V (Xhorse)

XHS-XDRK00EN

• Brand New
• Manufacturer: Xhorse

VVDI RKE BOX Remote Control Switching Box Support 3V1. Wiring Description:Remove the circuit boards in the original remote control, and connect to the main unit as the right picture shows (connect the white wire to buttons, red to the positive, black to the negative)Note: 3 kinds of remote button: 2-feet, 4-feet, and 5 feet buttons4-feet and 5-feet buttons: no direction distinction, but it must be soldered at the diagonals2-feet buttons: no direction distinction, and respectively solder the two feetoriginal remote controlpositivenegative remote wiring diagramIMPORTANT: Do not reverse the power cord on the remote control2. To get power via OBD or 12V constant power from the car3. Key/ Remote Matching and ClearingMatching Steps:Press SET button on the Host box (in the internal hole at the side of unit), then the buzzer beep twice, to go into the matching statePress any button on the new remote for a while until the buzzer beep continuously. Key matching is completed.Repeat the previous two steps to add another new key.Note:Up to six keys to match for one Host box; the key matching will fail if moreIn the matching state, the buzzer beeps once if the key cannot be detected for more than 10 seconds, and then automatically exit the matching state to go into the normal working state.Clearing Steps:Press SET button for a while until the buzzer beep continuously. All the keys matched previously are cleared and return to factory stateNote:If the key is lost or not to use, you can erase all the keys and then re-add all lost keys to ensure safety.BuzzerKey to be addedSET button4. To add the key embryo and anti-theft chip to the remote controlPackage Including:1pc x VVDI RKE BOX
