Uniview / UNV / IP / 5MP / Eyeball Camera / Fixed / 2.8mm Lens / Outdoor / WDR / IP67 / Smart Intrusion / Color Hunter / 3 Year Warranty / UNV-3615SE-ADF28KM-WL-I0

Description
Reviews (0)

High quality image with 5MP, 1/2.7\”CMOS sensor
5MP (2880*1620)@25fps; 4MP (2560*1440)@25fps;3MP (2304*1296)@25fps; 2MP (1920*1080)@ 30/25fps
Ultra 265, H.265, H.264, MJPEG
Intelligent perimeter protection, include cross line, intrusion, enter area, leave area detection
Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
Colorhunter technology ensures 24-hour full-color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 corridor Mode
Support built-in Mic
Support 256 G Micro SD card
IP67 protection
Support PoE power supply
Customer Service: USA: 800-860-7999 | Canada: 800-914-6008
Call 1-800-878-6604 for Dealer Prices!

	Camera
Sensor	1/2.7\” progressive scan, 5.0 megapixel, CMOS
Lens	[email protected]
DORI Distance	Lens: 2.8mm Detect: 63m (206.7ft) Observe: 25.2m (82.7ft) Recognize: 12.6m (41.3ft) Identify: 6.3m (20.7ft)
Angle of View (H)	102.0~80.2
Angle of View (V)	53.4~43.0
Angle of View (O)	121.0~94.7
Shutter	Auto/Manual, 1 ~ 1/100000s
Minimum Illumination	Color: 0.001Lux (F1.0, AGC ON)
WDR	120dB
Defog	Digital Defog
S/N	>56dB
LEDs Number	2
LED Distance	Up to 30m (98ft)
	Video
Video Compression	Ultra 265, H.265, H.264, MJPEG
H.264 code profile	Baseline profile, Main profile, High profile
Frame Rate	Main Stream: 5MP (28801620), Max 25fps; 4MP (25601440), Max 25fps;3MP (23041296), Max 25fps; 2MP (19201080), Max 30fps; Sub Stream: 720P (1280720), Max 30fps; D1 (720576), Max 30fps; 640360, Max 30fps; 2CIF (704288), Max 30fps; CIF (352288), Max 30fps; Third Stream: D1 (720576), Max 30fps; 640360, Max 30fps; 2CIF (704288), Max 30fps; CIF (352*288), Max 30fps;
Video Bit Rate	128 Kbps~16 Mbps
9:16 Corridor Mode	Supported
ROI	Up to 8 areas
OSD	Up to 8 OSDs
Privacy Mask	Up to 4 areas
White Balance	Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction	2D/3D DNR
Smart Illumination	Support
Flip	Normal/Vertical/Horizontal/180/90Clockwise/90Anti-clockwise
Dewarping	Supported
HLC	Supported
BLC	Supported
	Intelligent
Smart intrusion Prevention	Cross Line, Intrusion, Enter Area, Leave Area detection;
	Events
Basic Detection	Motion detection, Tampering alarm, Audio Detection
General Function	Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication
	Audio
Audio Compression	G.711
Suppression	Supported
Sampling Rate	8 KHZ
	Storage
Edge Storage	Micro SD, up to 256 GB
Network Storage	ANR, NAS(NFS)
	Network
Protocols	IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T), API
Client	EZStation EZView EZLive
Web Browser	Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
	Interface
Built-in Mic	Supported
Network	1 RJ45 10M/100M Base-TX Ethernet
	Certifications
Certifications	CE: EN 60950-1 UL: UL 60950-1 FCC: FCC Part 15
	General
Power	DC12V(25%), PoE(IEEE 802.3at) Power consumption: Max 12.7W
Dimensions ( x H)	110.5 x 94.1mm (4.4 x 3.7)
Weight	0.44kg (0.97lb)
Material	Metal
Working Environment	-30C ~ 60C (-22F ~ 140F), Humidity: 95% RH (non-condensing)
Strorage Environment	-30C ~ 60C (-22F ~ 140F), Humidity: 95% RH (non-condensing)
Surge Protection	2KV
Ingress Protection	IP67

True WDREquipped with sensor-based technology, camera with this technology can produce images with an extremely wide dynamic range. The WDR image sensor can capture several images with short and long exposures, then combining them into a single frame. there will be a greater difference between the brightest and darkest areas, and this is what we call a wide dynamic range or WDR (also known as High Dynamic Range, or HDR).

ONVIF COMPATIBILITY
If you want to add this camera to a security system already set up, thats no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, youll be able to set this camera up with your current system.
