Uniview / UNV / 8-Channel / 8MP / 4K / XVR / 1 SATA / HDD up to 8 TB / UNV-XVR301-08Q

Technical Specification

Video/Audio Input
IP Video Input	4-ch(only IP up to 12ch), each channel up to 4K
Two-way Audio Input	1-ch, RCA
Network
Incoming Bandwidth	56Mbps
Outgoing Bandwidth	64Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA Output	HDMI: 3840 x 2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Recording Resolution	8MP Lite/5MP Lite/4MP Lite /1080P/960P/720P/960H/D1/4CIF/CIF
Audio Output	1-ch, RCA
Synchronous Playback	8-ch
SATA	1 SATA interface
Capacity	Up to 8TB for each disk
External Interface
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface	Rear panel: 2 x USB2.0
Serial Interface	1 x RS485
General
Power Supply	12V DC Power Consumption: 8 W( without HDD )
Working Environment	-10C ~ + 55C ( +14F ~ +131F ), Humidity 90% RH(non-condensing)
Dimensions (WDH)	260mm 240mm 46mm (10.2\” 9.4\”1.8\”)
Weight (without HDD)	1.1 Kg ( 2.42lb
