Trine – 4100CDBM – 4-7/8 Electric Strike – One Box Solution – 8 Faceplates – Fire Rated ANSI – Optional Finish – Grade 1

TRN-4100CDBM

The Everything Strike – Works with almost all Cylindrical and Mortise locks on the market.

Covers 99%+ of Cylindrical & Mortise Lock configurations (without deadbolt), plus faceplates can be kept & used to help accommodate for door sag. We include the 8 most used faceplates to make specifying and installing easy

• Grade 1 Electric Strike — heavy duty construction, 1,000,000+ Life cycles — 3,250+ lbs. Holding Force
• Eight popular faceplates included — including the 8 most used faceplates in the box makes specifying and installing easy Covers 99%+ of Cylindrical & Mortise Lock configurations (without deadbolt), plus faceplates can be kept & used to help accommodate for door sag.
• 1 – 3/8 Shallow backset — the 4100 low profile electric strike can be used in 2 fire rated frames with 1/2 sheetrock ingress
• Low Current Draw — .240 Amp at 12DC makes it very PoE Friendly 12 & 24DC :: 12 through 24 AC. All the low voltage and amperage flexibility you need
• The included CCTS covers the gap when retrofitting the HES 1006, Folger Adams 712/732, and Von Duprin 6200 Series or even Trine EN Series strikes. No more ugly trim skirts. The CCTS always matches the faceplate finish.
• Why cut for a deadbolt 100% of the time when they are only used 5% of the time.
• Patented # US20110241361
• Cutout Specification A115.1 (with Slight Jamb Modification)

Faceplates Included:

• CC:Centered Cylindrical (Reference HES J faceplate) Cylindrical Locksets up to 3/4\” throw and all locksets center lined bolts: Corbin Russwin Security Bolt, Weiserbolt .
• MHO:Mortise High Offset (Reference HES KM faceplate) Accurate, Arrow, Best , Corbin Russwin, Falcon (1992M Series), Sargent (7800, 8200 & 9200 Series), Yale (8800).
• MMO:Mortise Medium Offset (Reference HES K faceplate) Baldwin, Marks, PDQ.
• MLO:Mortise Low Offset (Reference HES KD faceplate) Jackson, Sargent (7700 & 8100), Schlage (L Series), Yale (8700).
• CCRD – 4-7/8 x 1-1/4 Centered Cavity with Radiused Corners
• CRD7 – 6-7/8 x 1-1/4 Tall Centered Cavity with Radiused Corners
• CRD8 – 7-15/16 x 1-7/16 Tall Centered Cavity with Radiused Corners
• CRD9 – 9 x 1-1/4 Tall Centered Cavity
