TownSteel – XME-2050 – Electronic Mortise Lockset w/ Keypad – Deadbolt – 2-3/4\” Backset – Rigid Lever Set – Sentinel Lever – Fired Rated – Satin Chrome – Grade 1 | Mortise Locksets

Description
Reviews (0)

The XME-2000 is a standalone electronic function lock that provides keypad technology integrated with an ANSI Grade 1 heavy duty mortise lockset for greater security. Keypad technology simplifies the management of the system and provides ease of use. Maximum code capacity includes 1 master code, 90 user codes and 5 service codes. The XME-2000 provides two remote control terminals; One for a fore alarm system and the other for remote release by push button. The XME 2000 is quick and easy to program.

Features

Digital keypad mortise lock
Use keypad to lock or unlock outside lever
Mechanical key override
Rigid lever trim
ANSI/BHMA Certified heavy duty Grade 1 mortise chassis
Easy installation, easy programming

Specifications

Electronic Specifications
Application	Full indoor and outdoor
User codes	Up to 90
Communication	Multi-colored LED and Sound
Power Supply	4AA batteries
Battery Life	Up to 2 years
Operating Temperature	-31 to 151 F (-35 to 66C)
Mechanical Specifications
Chassis	A156.13 certified Grade 1 Mortise
Handing	Field reversible
Door Thickness	1-3/4\” standard
Backset	2-3/4\”
Latch Bolt	Stainless Steel, anti-friction split, 3/4\” throw
Faceplate	1-1/8\” x 8\”
Escutcheon	Wrought steel or zinc alloy, plated to match finish symbols
Lever	Sentinel Lever, Forged brass or cast zinc
Strike	ANSI strike, 1-1/4\” x 4-7/8\”, steel plated
Cylinder Specifications	6 pin Schlage C Keyway, standard
Finish	US26D- Satin Chrome
Fire Rated	3 Hours
Certifications	ANSI/BHMA A156.13 Grade 1 certified ANSI/BHMA A156.25 — Meets or exceeds all applicable requirements UL/ULC — UL 10C 3-hour rated BAA — Meets guidelines of the Buy American Act ADA — Meets requirements of the Americans with Disabilities Act RoHS — Meets requirements of EU RoHS Directive 2002/95/EC FCC — FCC part 15 certified
Manufacturer Warranty	1-year limited for electronic 5-year limited for finish 10-year limited for mechanical

Downloads

Data Sheet
Installation Guide
Templates
Programming Guide
Watch Programming Video Here

Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Townsteel directly at 877-858-088, [email protected] or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
