Jonard Tools – Mid Span Slit & Ring Tool (5 mm-10 mm)

The patented MS-326 Mid Span Slit and Ring Tool is designed to provide easy access to optical fibers in thin-walled outer jackets. Building on the popularity of the Jonard Tools MS-6 and MS-26 Fiber Optic Mid Span Slitting Tools, we have incorporated a ring feature in the tool to make it even more versatile.

• Consists of 5 precision slitting grooves and 5 precision ring grooves ranging in size from 5 mm to 10 mm
• One side of the tool performs radial/ring cuts and the other side slits the cable (longitudinal cut)
• Compact design weighing less than 2.5 oz with included tethering hole makes it perfect to use in tight spaces or on the go
• Indicator line on top of the unit indicates the position of the blade for accurate slitting and ringing
• This tool was specially designed for use on Corning fiber cables such as MiniXtend binderless FastAccess, HD MiniXtend, and other similar style cables
• Replacement blade set available, part number: MSB-5010
• Blades last for 5,000 slits/cuts
• All of our MS Series Mid Span Tools are patented for their unique design and functionality. Our MS-426 won the 2019 Cabling Installation & Maintenance Gold award for innovation and our MS-6 won the same prestigious award in 2018!

Groove Sizes: 5.0-5.6 mm | 6.0-6.6 mm | 7.2-7.8 mm | 7.8-8.4 mm | 9.4-10 mm

Specifications

Downloads:

• Spec Sheet
